The MMT Liquid Water Separation Tester is a precision instrument designed to evaluate the water repellency and separation efficiency of textile materials, coatings, and membranes. It quantifies liquid absorption resistance and hydrophobic performance using standardized spray and drainage methods, critical for waterproof fabric development and quality assurance.

Applications

Textile Manufacturing: Testing waterproof fabrics for outdoor gear

R&D: Developing hydrophobic coatings for medical textiles

Quality Control: Batch inspection of rainwear

Forensic Analysis: Evaluating fabric degradation from water exposure

Standards

AATCC 22 (Spray Rating), ISO 4920 (Water resistance)

Key Metrics:

Water Repellency Rating (0–5 scale)

Separation Efficiency (%)

Absorption Time (seconds)

Sample Size: 150×150mm (adjustable clamping)

Compliance Standards

AATCC 22 (Water repellency spray test)

ISO 4920 (Textile water resistance)

EN 343 (European waterproof standard)

GB/T 4744 (Chinese hydrostatic pressure test)

Features

Dual Test Modes:

Spray Test: AATCC 22 vertical hydrophobicity evaluation

Drainage Test: ISO 4920 dynamic water separation

Advanced Detection:

High-speed camera (120fps) with image analysis

AI-based droplet tracking (5 severity levels)

Real-time absorption rate calculation

Automation:

Auto-fill/empty water reservoir

Programmable nozzle angle adjustment

Self-cleaning drainage system

Technical Parameters

Accessoriess

1. Main unit;

2. Analysis software;

3. Conductivity tester

Test Procedures

1. Sample Preparation

Select the knitted/woven fabric sample to be tested, ensuring the sample is flat and undamaged.

2. Sample Installation

Install the sample into the testing area between the upper and lower concentric liquid sensors of the testing instrument, ensuring the sample is in close contact with the test area.

3. Instrument Adjustment

Check the condition of the instrument's infusion tubing, probes, and other components, and adjust the instrument to a ready state.

4. Simulated Droplet Application

Through the infusion tubing of the upper sensor, evenly drip simulated human sweat onto the fabric surface according to the set fixed concentration and amount.

5. Test Startup

Start the instrument and use the sensor probes to monitor the resistance changes at different stages (to reflect the absorption/diffusion of the liquid in the fabric).

6. Parameter Acquisition

After the test, read the parameters output by the instrument (upper/lower layer wetting time, sweat absorption rate, maximum diffusion radius, etc.) to complete the evaluation of the fabric's liquid moisture management capability.

FAQ

1. What is this product?

It is a precision physical laboratory instrument specifically designed to quantitatively measure the ability of air to pass through fabrics or porous materials.

2. What is this product used for?

It helps you quantify a fabric's “breathability.” Through air permeability values, you can directly determine whether a fabric feels stuffy or cool, or evaluate the filtration resistance of industrial filter materials.

3. How does this product work?

The instrument uses a fan to create a specific pressure difference across both sides of the sample. Sensors detect the airflow passing through this area and automatically convert it into air permeability.

4. Why is this product important?

Breathability directly determines clothing comfort. For masks and protective suits, breathability data is a critical indicator balancing safety protection and respiratory ease.

5. Which industries is this product suitable for?

It is suitable for textile printing and dyeing enterprises, apparel brand quality control departments, medical protective equipment manufacturers, automotive interior R&D centers, third-party testing institutions, and university research laboratories.
