This product uses fluorescent UV lamps, combined with temperature and humidity device  to simulate the material decline in color, brightness, strength and cracking, spalling, powder, oxidation damage via the high temperature sun light (UV), high humidity, condensation, dark cycle etc. At the same time, through the synergy between UV and moisture resistance ability of single or single material makes wet ability weakening or failure, which is widely used to evaluate the performance of weather resistant materials, equipment is to provide the best sunshine UV simulation.

Usage and maintenance are of low cost, easy to use.  Equipment uses program controller can automatic control the test cycle, with high automatic high degree. In addition, it has stable light performance and high rate of repetition test results.

The UV aging test chamber is suitable for all kinds of geo-synthetics, such as light resistance, weather resistance and light ageing

The exposure test of the sample was carried out in a fluorescent UV lamp vessel in a controlled environment. It can simulate and strengthen the environmental factors in the natural climate that are affected by light, heat, humidity, and rainfall as the main aging. It can simulate the accelerated test under long term exposure to obtain the results of the weather resistance of the material.

Ultraviolet tester Standards

JTG E50 T1164The methods of geo-synthetics for highway engineering

GB/T 14522-93Accelerated weathering test method for plastics, coatings and rubber materials used for machinery industrial products.

GB-T16422.3-1997Plastics--Methods of exposure to laboratory light sources--Part 3: Fluorescent UV lamps

ISO4892-3:1994Plastics - Methods of exposure to laboratory light sources - Part 3: Fluorescent UV lamps

Structures

Main features: light, condensation, automatic cycle control, real-time monitoring and display

Light temperature: RT + 10 ℃ ~ 70 ℃

Condensation temperature: 50 ℃

Condensation method: steam humidification condensation

Temperature uniformity: ± 3 ℃

Irradiation intensity: 0.55W / m2

Light / condensation cycle: 0 ~ 9999h,59min. It can be set (such as: 4H / 4H or 8H / 8H)

Lamp center distance: 70mm

Sample and lamp plane distance: 55mm

UV lamp: UV-A340 or UV-B313 (optional)

UV wavelength: (UVA) 315 ~ 400nm; (UVB) 280 ~ 315nm

FAQs

1. What is a UV Lamp Aging Test Tester used for?

It is used to evaluate the aging resistance and weathering performance of materials exposed to UV radiation.

2. What materials can be tested with this equipment?

It is commonly used for plastics, rubber, coatings, textiles, and other materials requiring UV aging evaluation.

3. What changes can be evaluated during UV aging testing?

Typical evaluations include color fading, surface cracking, discoloration, and changes in mechanical properties.

4. Why is UV aging testing important?

It helps manufacturers understand how materials perform under prolonged UV exposure and supports product quality control.

5. Which standards are applicable to UV lamp aging testing?

Applicable standards depend on the test method and equipment configuration, such as ISO 4892-3 or ASTM G154. The specific standard should be confirmed according to the material and testing requirements.
